Overview
The DSE8660 is a microprocessor-based generator set controller that provides automatic engine start/stop sequencing, AC power monitoring, and alarm protection for single diesel or gas generator units. It integrates digital measurement, programmable logic, and communication interfaces into a single panel-mounted module.
Key Features
- Multi-Unit Load Sharing — Full isochronous load sharing with kW and kVAR control for up to 32 generator sets operating in island or grid-parallel mode
- 7-inch Touchscreen HMI — High-resolution color display with customizable single-line diagrams, instrument pages, and alarm management screens
- Advanced Power Management — Automatic generator start/stop based on load demand, peak shaving, and base-load/peak-load operation modes
- Comprehensive Communication Suite — Ethernet, RS485, RS232, USB, CAN, Modbus TCP/RTU, BACnet, SNMP, and IEC 61850 for utility-grade SCADA integration
- Sync-Check & Bus Control — Dedicated sync-check relay output with programmable phase angle, voltage, and frequency matching windows for breaker control
- Enhanced Cybersecurity — User access control with password levels, event audit trail, and secure communication protocols for critical infrastructure
Technical Specifications
| Parameter | Value |
|---|---|
| ———– | ——- |
| Model | DSE8660 |
| Type | Digital Generator Controller |
| Power Supply | DC 8V to 35V Continuous |
| Communication | RS485, CAN, SMS |
| Function | Mains Control Module, RS485/CAN/SMS |
| Display | 10″ TFT Colour 1024×600 |
| Frequency | 50/60 Hz Selectable |
Compatibility
DSE8660 is the top-tier multi-unit paralleling controller in the DSE 8600 series, positioned above DSE8610. Designed for complex power plants with up to 32 generators plus utility grid connection. Panel cutout: 276×218mm. Compatible with: DSE8660, DSE8610, DSE8600 series, DSE8900 gateway.
Why Choose ZenixPower
- Full-Feature AMF — Automatic mains failure detection, engine start/stop sequencing, and load transfer control
- Multi-Protocol Communication — RS485 Modbus RTU, CAN J1939, and SMS alarm notification for remote monitoring
- Wide DC Supply — Operates from 8V to 35V DC, tolerating cranking voltage drop without reset
- Heavy-Duty Relays — 16A/250VAC rated outputs for fuel, start, and auxiliary control with replaceable relays
- Universal Compatibility — Works with magnetic pickup, alternator sensing, and CAN ECU engine types
- Pre-Configured Files — SmartGen/DSE/ComAp default configurations available to reduce commissioning time
Compatible Generators Large power stations with multiple generator sets operating in parallel, 200-5000kW, requiring automatic synchronization, load sharing, and power management.
Competitors DSE8610 (Deep Sea), HGM7100N (SmartGen), DKG500 (Datakom).
Specification Comparison
| Parameter | DSE8660 | DSE8610 | HGM7100N | DKG500 |
|---|---|---|---|---|
| Brand | Deep Sea (UK) | Deep Sea (UK) | SmartGen (China) | Datakom (Turkey) |
| Generator Capacity | Mains Control Module, RS485/CAN/SMS | Up to 16 units | Up to 16 units | Up to 16 units |
| Display | 7″ TFT touchscreen 800×480 | 7″ TFT touchscreen | 7″ TFT touchscreen | 4.3″ TFT touchscreen |
| Communication | Ethernet, RS485/232, USB, CAN, Modbus, BACnet, SNMP, IEC 61850 | Modbus TCP/RTU, BACnet, SNMP | Modbus TCP/RTU | Modbus TCP/RTU |
| Digital Inputs | — | 12 | 12 | 12 |
| Relay Outputs | — | 12 | 12 | 8 |
| Event Log | — | 250 events + waveform | 200 events | 150 events |
| Price | Contact Us | $500-800 | $300-500 | $250-400 |
